ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder
ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder - Image 2
ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder - Image 3
ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder - Image 4
ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder - Image 5
ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder - Image 6

ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder/ GPS Navigator Echo Sounder /Depth Sounder

Rp18.079.153 Original price was: Rp18.079.153.Rp15.079.153Current price is: Rp15.079.153.
In Stock

This product has been added to 1 people'scarts.

Order on WhatsApp
In Stock
Add to wishlist
  • Pre-Order Available (Estimated ±15 Day Delivery)
  • 7 day unit replacement guarantee(Video Unboxing Required)
  • Including shipping costs, sent by Supplyinx.com
  • Pick up at a supplyinx.com collection point is possible
  • 24/7Customer service
SKU: 1005007224581421
Category:

Description



ONWA KP-25F 5 Inch GPS Chart Plotter Fish Finder / GPS Navigator Echo Sounder / Depth Sounder

Deskripsi Produk
ONWA KP-25F adalah perangkat multifungsi yang menggabungkan GPS chart plotter, fish finder, dan echo sounder dalam satu unit dengan layar 5 inci. Alat ini dirancang untuk membantu para pemancing dan pelaut dalam navigasi, pencarian ikan, dan pengukuran kedalaman air secara akurat dan efisien.

Dengan GPS navigator terintegrasi, KP-25F menyediakan peta laut dan posisi kapal secara real-time, sementara echo sounder dan fish finder membantu mendeteksi keberadaan ikan serta memetakan kedalaman dasar perairan. Desain kompak dan mudah digunakan menjadikannya perangkat ideal untuk berbagai aktivitas di laut.

Fitur Utama

✅ Layar 5 Inci: Tampilan jelas dan mudah dibaca
✅ GPS Chart Plotter: Navigasi akurat dengan peta laut terintegrasi
✅ Fish Finder: Deteksi ikan secara efektif dan presisi
✅ Echo Sounder / Depth Sounder: Pengukuran kedalaman air yang akurat
✅ Multifungsi: Solusi lengkap untuk navigasi dan pencarian ikan
✅ Desain Kompak dan User-Friendly: Mudah dioperasikan di kapal

Spesifikasi Teknis (Umum)

Model: ONWA KP-25F
Fungsi: GPS chart plotter, fish finder, echo sounder
Layar: 5 inci berwarna
Material: Bodi tahan lama dan tahan air
Berat: Ringan dan portabel

Aplikasi

Navigasi Laut: Membantu posisi dan perencanaan rute kapal
Memancing: Mendeteksi keberadaan ikan dan area potensial
Pengukuran Kedalaman: Memastikan keamanan pelayaran dengan data kedalaman
Aktivitas Laut Profesional dan Hobi: Mendukung kebutuhan berbagai pengguna

Ringkasan
ONWA KP-25F adalah perangkat multifungsi dengan layar 5 inci yang menggabungkan GPS chart plotter, fish finder, dan echo sounder. Dengan fitur lengkap dan desain praktis, alat ini mendukung navigasi dan pencarian ikan secara akurat di laut.

KP-25F (NEW!)

5-inch GPS Chart Plotter Fish Finder

Specifications

 Plotter Characteristics

Waypoints/icons
12,000 user waypoints with name, symbol,

3 system waypoints: MOB,Start,cursor

10 proximity waypoints

Routes
30 routes waypoint up to 170 points each,

plus MOB and Track Navigation or Goto Track modes

Tracks
16,000 points automatic track log;

10 saved tracks (up to 16,000 track points each)

lets you retrace your path in both directions

Alarms
XTE, Anchor drag, arrival, speed, voltage, proximity waypoint,

Timer and AIS (CPA and TCPA) alarm

Drawing
1000 Drawing Marks; 2000 Drawing Lines (40 points each);

1000 Drawing Place Name; 8 colors for Drawing

Pallete
Normal

Daylight exposed to sunlight

Night in dark environment

NOAA paperchart colors

Tides
Built-in Worldwide Tide Data
Position Format
Lat/Lon
Basemap
Worldwide
External Map
Compatible with K-Chart 2.0, K-Chart 3.0, C-Map Max and Navionics+
User Data Storage
Internal backup of user settings or external SD-card
Plot Interval
5secs to 60 mins or 0.01 to 10nm
Plotting Scales
0.001 to 700nm
AIS
700 targets display
AIS Target Tracking
10 Manually saved tracks (300 points each)
AIS Messaging
ONWA AIS to ONWA AIS
Perspective view
On/off (available for C-Map only)
Celestial
Sunrise/Sunset Moonrise/Moonset



 GPS Receiver Characteristics

Receiver
50 parallel channel GNSS receiver continuously tracks and

uses up to 50 satellites to compute and update your position

Acquisition time
Cold start: 29 seconds

Hot start: 1 second

Update rate
1 second
Accuracy
Position:3 meters(95%) without S/A

Velocity: 0.1 meter/sec without S/A

SBAS
Supported
GNSS
GPS+ Beidou+ Galileo+ Glonass
Dynamics
Altitude: 18,000 m

Velocity: 515 m/s

Datum
WGS 84 & user defined
Antenna
GPS Patch Antenna



 GPS Interface (NMEA0183)

GPS Data
RS422 input/output, NMEA 0183 V3.01 and V4.11
GPS Input Baudrate
Auto Scan (4800, 9600, 19200 and 38400)
GPS Output Baudrate
Selectable among 4800, 9600, 19200 and 38400



 AIS Interface (NMEA1083)

AIS Data
RS232 output VDO, VDM, GGA, GSA, GSV and RMC
AIS Output Baudrate
38,400



 Echo Sounder Characteristics

Echo Color
16 colors (including background color) according to echo intensity. The background color is selectable from blue, light blue, white and black
Basic Range
Meters 5/10/20/40/80/150/200/300/600/1000

Feet 15/30/60/120/200/400/600/1000/2000/3000

Fathoms 3/5/10/20/40/80/150/300/600

*The basic ranges can be changed on the system menu.

Range Shift
Up to 1000 meters (3000 feet,600 fathoms)
Zoom Range
Times 2,3,4 and 6 ranges
Bottom Lock Expansion Range
5/10 meters,10/20 feet,2/5 fathoms
Auto Mode
Automatic adjustment of range and gain
Display Mode
High Frequency (200K),Low Frequency (50K), Dual (200K and 50K 1/2 display on each),

Zoom (200K and 50K zoom) and A-scope Display

Zoom Display
Marker Zoom, Bottom Zoom and Bottom-lock Expansion
Display Advance Speed
Lines/TX:Freeze, 1/8, 1/4, 1/2, 1/1, 2/1, 4/1, 6/1,8/1 and 10/1
TX Frequency
50 and 200kHz (alternately transmitted)
Power Output
600W
Pulse-length/TX rate
Display End Depth (m)
5
10
20
40
80
150
200
300
600
1000
Pulse-Length 200K(µs)
120
220
320
520
920
1020
1020
1020
1020
1020
Pulse-Length 50K(µs)
170
270
370
570
970
1070
1070
1070
1070
1070
TX Rate(pulse/min)
2000
1333
706
353
171
98
75
53
38
27
TX period(millisecond)
30
45
85
170
350
610
800
1120
1580
2200
Interference Rejecter
Rejects unwanted signals by comparing last and present echoes in strength.
Alarm
Fish and Bottom alarms,

Temperature alarm (sensor required)



 NMEA0183 Sentence Supported

INPUT
(Auto scan Baudrate)

GGA, GLL, GSA, GSV, RMC, HDG, HDM, HDT

VTG, ZDA, MTW, VWR, VWT, MWD, VPW, VHW

TLL, TTM, VDO, VDM, GNS, MTA

RMA, DBT, DPT, MWV, BWC, XTE, ZDL, WPL, AAM,

APB, BOD, RMB, DSC, MDA, RPM, XDR

OUTPUT
Baudrate: Selectable 4800, 9600, 19200, 38400

GGA, GLL, RMC, GSA, GSV, AAM, APA

APB, BOD, BWC, BWR, DBT, DPT, HDT

MTW, RMB, TLL, VTG, WPL, XTE, ZDA

ZTG, ZDL, MWD, VPW, VWR, VWT

OUTPUT for Autopilot
APA, APB, BOD, XTE







 Power Supply


10.5 to 34VDC, current drain <1.0A at 12V



 PHYSICAL

Size
143.1mm(H)X215.3mm(W)X63.1mm(D)
Weight
1.0 kg
Display
5-inch Color TFT dayview LCD, 800×480 pixels
Waterproofing
Display unit (Front Panel): IP66

Antenna unit: IP66

Temperature range
Display unit: -15℃ to +55℃

Antenna unit: -25℃ to +70℃



 Equipment List


Display unit

Quick manual

GPS Patch Antenna with 4m cable (SMA connector)

Mounting Brackets

Standard accessories pack
