LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module
LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module - Image 2
LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module - Image 3
LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module - Image 4
LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module - Image 5
LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module - Image 6

LDJ High Precision Laser Distance Sensor 4-20ma 100m Long Range Laser distance meter module

Rp5.687.402 Original price was: Rp5.687.402.Rp3.687.402Current price is: Rp3.687.402.
In Stock

This product has been added to 19 people'scarts.

Order on WhatsApp
In Stock
Add to wishlist
  • Pre-Order Available (Estimated ±15 Day Delivery)
  • 7 day unit replacement guarantee(Video Unboxing Required)
  • Including shipping costs, sent by Supplyinx.com
  • Pick up at a supplyinx.com collection point is possible
  • 24/7Customer service
SKU: 1005008575355089
Category:

Description

Deskripsi Produk

LDJ High Precision Laser Distance Sensor adalah modul pengukur jarak laser dengan jangkauan hingga 100 meter dan dukungan output 4–20mA, yang memungkinkan integrasi mudah ke berbagai sistem industri maupun otomasi. Dengan akurasi tinggi dan desain kompak, sensor ini sangat ideal digunakan untuk pengukuran jarak, pemantauan posisi, serta kontrol proses secara real-time.

Fitur Utama

  • Jangkauan hingga 100m dengan hasil pengukuran presisi.

  • Output 4–20mA: Kompatibel dengan sistem kontrol industri dan PLC.

  • Akurasi Tinggi: Memberikan hasil stabil pada berbagai kondisi.

  • Desain Modular: Ringkas dan mudah diintegrasikan ke perangkat lain.

  • Pengukuran Real-Time: Cocok untuk monitoring jarak dan posisi secara terus-menerus.

  • Konstruksi Tahan Lama: Dibuat untuk ketahanan penggunaan lapangan.

Pengaplikasian

LDJ Laser Distance Sensor banyak digunakan pada:

  • Industri otomasi untuk deteksi posisi dan kontrol proses.

  • Logistik & pergudangan untuk pengukuran jarak otomatis.

  • Pemetaan & surveying yang membutuhkan pengukuran jarak presisi.

  • Industri konstruksi & pertambangan untuk monitoring level material.

  • Sistem keamanan & monitoring berbasis sensor jarak jauh.



Products Description
LDJ Module
The LDJ laser distance sensor represents a sophisticated sensing solution harnessing laser technology for precise distance measurement. Designed to facilitate secondary development and seamless data communication, it offers versatile compatibility with various communication interfaces including USB, TTL, RS232, RS485, and Bluetooth. Its customizable features include dual-color laser options—green and red—and selectable frequencies of 3Hz, 10Hz, and 20Hz, ensuring adaptability across diverse operational environments.

Product Parameters
Range Distance
0.03-100m/120m/150m/200m
Frequency
3Hz/10Hz/20Hz
Resolution
±3mm
Measuring Time
0.05~4s
Laser Type
620nm~690nm, <1mW Red laser
Laser Class
Class II
Operating Temperature
0~40鈩� 锛�32~104鈩夛級
Storage Temperature
-25~60 鈩� (-13~140 鈩�)
Power Consumption
<[email protected]
Size
64*40*18mm
Weight
14g
Data Interface
UART/RS232/RS485/Bluetooth

Features

Equipped with both single measurement and continuous measurement modes, it boasts robust performance capable of sustaining 24-hour continuous operation. Widely deployed in Industrial Automation, Intelligent Warehousing, Rail Transportation, and engineering measurement systems, the LDJ laser distance sensor embodies cutting-edge functionality tailored to demanding professional applications.


Product Details
Laser Emisson And Reception


Our laser distance sensor features precision lenses for laser emission and reception.
* The emission lens ensures a focused laser beam for long-range accuracy.
* The reception lens captures reflected signals for precise measurements.
* Anti-reflective coatings improve performance in varying environments.
This setup guarantees reliable, high-accuracy measurements across multiple applications.


Communication Port

Our sensor supports a variety of serial interfaces, including:
* TTL, USART, RS232, and RS485 for flexible communication.
* Compatible with Arduino and Raspberry Pi, ideal for DIY projects and custom development.
With these interfaces, the sensor adapts easily to different systems, making it perfect for automation, robotics, and IoT projects.

Pin Definitions and Wiring

Below is an overview of the pin definitions and connection procedures for the laser distance sensor module:
* VCC: Power supply input (3.3V – 5V). Ensure stable voltage to avoid measurement errors.
* GND: Ground connection, common for both power and signal.
* TX: Transmitter pin for sending serial data to the host (supports TTL, RS232, or RS485 protocols based on the configuration).
* RX: Receiver pin for receiving data from the host device.
* MODE: Switch pin for toggling between single-measurement mode and continuous mode.
* EN: Enable pin to activate or deactivate the module, allowing for power-efficient operations.
Test Software Platform

The included test software provides real-time measurement data with:
* Line graphs showing measurement trends
* Data tables with timestamps, distance values, and signal strength
* Export options for further analysis

This tool ensures users can monitor performance and optimize applications with ease.

Application


Industrial Automation



Measure the level of stored material, enabling efficient inventory management and ensuring optimal filling and emptying processes.



Transfer Belt



Measure distances between objects or materials being transferred along the belt, ensuring precise positioning and alignment in industrial conveyor systems.



Engineering Surveying



Measure distances between points and objects, facilitating precise mapping, construction layout, and terrain modeling tasks.



Intelligent Logistics



Measure distances between objects and guide automated systems for efficient navigation, sorting, and warehouse management.



Granary And Other Warehouse



Measure the level of stored material, enabling efficient inventory management and ensuring optimal filling and emptying processes.



Robot Vacuum Cleaner



The robot can measure the distance of obstacles ahead to achieve intelligent obstacle avoidance. At present, it is widely used in service industry
