Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station
Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station - Image 2
Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station - Image 3
Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station - Image 4
Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station - Image 5
Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station - Image 6

Hi-Target HTS-521L10 Total Station Reflectorless Range 1000m Total Station

Rp64.238.719 Original price was: Rp64.238.719.Rp58.238.719Current price is: Rp58.238.719.
In Stock

This product has been added to 7 people'scarts.

Order on WhatsApp
In Stock
Add to wishlist
  • Pre-Order Available (Estimated ±15 Day Delivery)
  • 7 day unit replacement guarantee(Video Unboxing Required)
  • Including shipping costs, sent by Supplyinx.com
  • Pick up at a supplyinx.com collection point is possible
  • 24/7Customer service
SKU: 1005009372153997
Category:

Description

Hi-Target HTS-521L10 adalah total station presisi tinggi dengan kemampuan pengukuran tanpa prisma (reflectorless) hingga 1000 m. Dirancang untuk pekerjaan survei profesional, instrumen ini menggabungkan akurasi sudut 1 detik, optik berkualitas, serta layar warna modern untuk meningkatkan produktivitas di lapangan. Cocok digunakan dalam survei topografi, konstruksi, maupun pemetaan infrastruktur.

Spesifikasi Utama

  • Akurasi Sudut: ±1″

  • Jarak Tanpa Prisma: hingga 1000 m

  • Jarak dengan Prisma: hingga 5000 m

  • Optik: Pembesaran 30×, fokus minimum 1,5 m

  • Layar: Color LCD ganda, antarmuka user-friendly

  • Memori: Internal + USB eksternal

  • Komunikasi: USB, RS-232, Bluetooth (opsional)

  • Fitur Tambahan: E-bubble, dual-axis compensator, multilingual menu

  • Daya: Baterai Li-ion isi ulang, durasi kerja ±8–10 jam

  • Ketahanan: IP66 tahan air & debu, tahan jatuh ±2 m

Pengaplikasian

  • Survei topografi & geodesi presisi tinggi

  • Setting-out proyek sipil & konstruksi (jalan, jembatan, gedung)

  • Pengukuran batas lahan & properti

  • Pemetaan infrastruktur & area urban

Global useful Hi-target ZTS-421L10 /HTS-521L10 Survey instrument with High precision 2” accuracy Hi-target survey total station
SPECIFICATIONS

Model
HTS−521L10
Angle Measurement

Angle Measuring Principle
Absolute Encoding
Minimum Readout
1″
Accuracy
2″
Distance Measurement (Prism Mode)

Single prism'(General/Good Atmosphere)
5000m/6000m
Accuracy (Fine/Quick/Tracking)
2 mm + 2 ppm
Measuring Time³(Repeat/Tracking)
0.5s/0.3s
Distance Measurement (Reflectorless)

Range²(The target is Kodak white board with reflect rate of 90%)
1000 m
Accuracy(It may change according to the different reflector conditions)
3mm+2 ppm
Measuring Time³
Approx.1s
Telescope

Magnification
30x
Field of View
1°30′
Minimum Focusing Distance
1.5m
Reticle
lluminated
Tilt Sensor

System
Dual-axis liquid tilt sensor
Working Range
±3′
Accuracy
1″
Communication

Internal Data Memory
Approx.80,000 Points
Interface
Standard RS232,USB
Wireless communication
Blue tooth
Data Format ASCII

Power Supply

Battery Type
Rechargeable high-energy lithium battery
(Type-C for direct charging)
Voltage/Capacity
7.4V/3000 mAh
Operating Time
Optimal 36 hours(Continuous angle measurement
every 30 seconds)/18 hours (typical)
Measuring Times
Approx.30000 times
Other

Display
2.8 inch 240*320 pixel highlight color display
Keyboard
2 sides alphanumeric backlit silicone keyboard.
Trigger key.
Plummet

Type
Laser point,4 brightness levels adjustment/
Optical plummet(optional)
Environment

Operating Temperature
-20鈩儈50鈩�
Storage Temperature
-40鈩儈70鈩�
Temperature and Air Pressure Input
Automatic sensor
Dust&Water Proof(IEC60529 Standard)
IP65
